MagicaCSG @ ephtracy [Beta Version 0.4.5]

A Nondestructive Signed Distance Field (SDF) Editor and Path Tracing Renderer Created by Ephtracy.

Previous Next

Update Log

FAQ

• Requirement: Win64, OpenGL 4.6, 2GB GPU Ram
• Display nothing: Force windows to use the dedicated gpu (via high performance power plan or gpu panel or Settings > System > Display > Graphics Settings).
• UI too small: Ctrl +/- to scale the ui. or change ui_scale in config.txt.
• Check [Patreon] for more tutorials and information.
• An unofficial tutorial: [MagicaCSG 0.4.1 Tutorial].

0.1.x

• [0.1.0]
  • Scene Editor.
  • Independent Resolution for each volume (Press ⊕ / ⊖).
  • Support Instancing Rendering.

0.0.x

• [0.0.5]
  • Revolve /Two-sided Cone Modes.
  • New Triangle Variant Shapes: 1. 4-Point Quadrilateral (Triangle->P4) 2. 3D Triangle (Triangle->P3 + 3D) 3. 3D Tetrahedron (Triangle->P4 + 3D) 4. 4-Point Rhombus Shape (Triangle->PD + Rhombus Modifier + Vertex/Top)
• [0.0.4]
  • Layer & Stroke visibility: click the eye icons besides layers/strokes to toggle the visibility. hotkey: [CTRL+H/CTRL+SHIFT+H].
  • 2D/3D Line/Bezier, Rhombus stroke shapes: the line can have up to 4 control points now (but without taper). 2D/3D Line/Bezier splines are combined.
  • Curved and centered line taper: click the egg and football icons in [Stroke->Taper]. It only works with [Line->P0] control points.
  • Stroke brush: a tool (on the top bar) to add new strokes by clicking on the surface. changing [Stroke->Properties] only affects the next added stroke, not the selected ones.
  • Snap move offset and rotate angle: e.g., rotate multiples of 15 degrees [ALT+Move/Rotate Gizmo]. change snap value in [Gizmo->Snap].
  • Snap control points: for [Line/Bezier] splines, you can [CTRL+Drag] the control points to snap the control points to the surface.
  • Snap array duplicates: you can [CTRL+SHIFT+Drag] strokes to multiple duplicate strokes and place them along the surface.
  • Stroke color opacity: you can change the color opacity of strokes when using [Replace Operation] to color models (click the [Droplet Icon] to show the [Opacity] sliders).
• [0.0.3]
  • 3/4-point 2D/3D Bezier spline: choose [Bezier/Bezier3D]->[P3/P4].
  • Trapezoid: change [Triangle]->[Top Width/Vertex].
  • L-norm Sphere: change [Sphere]->[Power].
  • Drag & drop strokes: from the stroke menu to the scene.
  • Array duplicates: change the [Number] on the top bar; [Shift+Gizmo] to create multiple duplicates while transforming the strokes.
  • Free move tool: move strokes along the surface.
  • Stroke level transform mode: transform strokes locally.
  • Scale distance transform mode: transform stroke positions only.
  • Enable/disable selecting strokes in [Replace] mode.
  • Copy/Paste stroke transformations.
  • Align stroke rotation to the axes of the current space.
  • Align origins and axes of strokes.
• [0.0.2]
  • New Stroke Shapes: Quadratic Bezier (3-point), Oval (Cylinder), Star (Polygon)
  • Icons: add icons to stroke panel and list.
  • Stroke List:: use SHIFT/CTRL to multi-select strokes in the stroke list. use right-click menu to rename layers and strokes.
• [0.0.1]
  • Marching Cube mesh export: IO->Mesh->Export.
• [0.0.0]
  • Shift+Drag any gizmo to duplicate strokes.
  • Shift/Alt+shift for multi-selection.
  • Drag on the surface of selected strokes to freely rotate them.
